Knuth KKS 250 T Circular Cold Saw ( Part No. 102119) Proven classic model for workshops- rugged and lasting.
Knuth KKS 250 T Circular Cold Saw ( Part No. 102119)
Ex stock availability . 4 weeks. Subject to no prior sales.
Highlights
KKS 250 T Circular Cold Saw
Quick- action
vise Base
Coolant system
1 saw blade
Longitudinal stop
The manual KKS 250 T cold circular saw is equipped with everything that is necessary for processing smaller tubes and profiles. All models can be precisely mitred. The models with a 250/275 mm saw blade have a clamping vice with a quick-release function. The supplied stand makes the installation of the machine flexible. Due to their compact design and high angle accuracy, cold circular saws are used in metalworking shops and metal construction companies.
- Simple operation, robust design and precise angle cuts make cold circular saw the basic equipment of every workshop
- This series of circular cold saw machine is ideal for cutting solid materials, pipes and profiles made of steel, iron and light metal
- The saw cut is guided by the operator using a hand lever with an on switch that is ergonomically integrated in the handle
- The KKS 250 T model is characterized by a stable vice with quick-clamping device and counter holder, ideal for small series
- The miter adjustment up to +/- 45 degrees is done by swiveling the gear head
- A central clamping lever integrated in the machine frame fixes the selected angle setting
- All models have high-torque motors,
- A generously dimensioned deflection gear runs in an oil bath, requiring little maintenance and reducing wear
- A stable machine base enables the machine to be set up in a space-saving manner
- An integrated coolant device is part of the standard equipment of all models
Technical Details
| WORKSPACE | |
|---|---|
| max. saw blade Ø | 250mm |
| shaft diameter | 32mm |
| number of revolutions | 42 rpm |
| vise opening width | 100mm |
| working height | 960mm |
| CUTTING PERFORMANCE | |
|---|---|
| Cutting capacity 0° (round) | 60mm |
| Cutting capacity 0° (square) | 55mm |
| Cutting capacity 0° (rectangular) (length x width) | 75mm x 45mm |
| Cutting capacity 45° L (round) | 55mm |
| Cutting capacity 45° L (square) | 50mm |
| Cutting capacity 45° R (round) | 55mm |
| Cutting capacity 45° L (rectangle) (width x length) | 55mm x 45mm |
| Cutting capacity 45° R (square) | 50mm |
| Cutting capacity 45° R (rectangle) (length x width) | 55mm x 45mm |
| DRIVE POWER | |
|---|---|
| Main drive engine power | 1.1kW |
| MASS AND WEIGHT | |
|---|---|
| Dimensions (length x width x height) | 0.92m x 0.48m x 1.71m |
| Weight | 143kg |
