Knuth KRM/ST 30/5 Motorised 3 Roller Roll Bending Machine ( Part No. 130786) Modern design,user friendly machine with asymetrical mounted rolls
Knuth KRM/ST 30/5 Motorised 3 Roller Roll Bending Machine
( Part No. 130786)
Modern design , user friendly machine with asymetrical mounted rolls
Availability. 4 weeks, subject to no prior sales
Highlights
Knuth KRM ST Series Motorised 3 Roller Roll Bending Machines
The models in our KRM ST series perform round bending work on workpieces up to 3000 mm longer. The heavy, medium-capacity round bending machines have a solid, closed machine frame and a motor-driven adjustable rear roller. Conical bending and bending are among the features that allow you a wide range of applications for individual production in metalworking, steel and metal construction.
- Asymmetrical construction
- Motor drive with 4 kW
- Hardened rollers
- conical bending device
Knuth KRM ST 30/5 Motorised 3 Roller Roll Bending Machine
- Hardened rollers, also suitable for processing stainless steel
- conical bending device
- Engine. rear roller adjustment
- Solid steel construction
- Quality steel rollers
- 2 powered rollers
- Swing-out top roller
- Lower roller manually adjustable, optionally motorized
- Optionally available with extended roll ends for profile bending rolls
- central lubrication
- Separate control panel
- According to CE
Technical Details
WORKSPACE
| sheet thickness (max.) | 5mm |
| working length | 3050mm |
| roller diameter | 200mm |
| max. sheet thickness e.g. bending | 4mm |
| Bend diameter (min.) | 300mm |
| DRIVE POWER | |
|---|---|
| Main drive engine power | 4kW |
| MASS AND WEIGHT | |
|---|---|
| Dimensions (length x width x height) | 5.2m x 0.95m x 1.3m |
| Weight | 4000kg |
Standard Equipment
hardened rollers
conical bending device
motorized rear roller adjustment
automatic central lubrication
operating instructions
Optional Equipment
Tooling options available
Digital display for rear roller adjustment
